Name: SACFS Recognised Airbases and Airstrips

Display Field: airbase

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: The airstrips selected for use to support aerial firefighting will be categorised by State Aviation Operations and use the following principals and minimum requirements: a demonstrated, historical and justified need; secure tenure of the airstrip; the runway should be a minimum of 900 metres long, but should exceed 1,000 metres if possible, with the option to extend to 1,200 metres; it should be on level or near level ground with no obstructions at either end, free from any hazards to aircraft; where possible orientation of the runway should be in the north to west quadrant; width of airstrip should be a minimum of 60 metres; airstrip should have direct access to the public road network; water supply should be a minimum of 45,000 litres static supply with the capacity to be re-supplied from mains, dam, or bore; identified personnel or brigades who are committed to, and can support aerial firefighting operations; and the airstrip will require an area for filling that is a safe distance from the runway.Within the Primary Response Zones (PRZs), there are approximately 25-30 kms between airbases. State aviation Operations used the principal that SACFS needs an aircraft on initial response, over an incident within ten minutes, and a returning aircraft every ten minutes after initial response in the PRZs. Using an initial response of two single engine air tankers, known air speed and turnaround times, SACFS can achieve this requirement with the above radii. Within the Secondary Response Zone populated areas, there are approximately 50-60 kms between airbases. This provides for a response time for a fixed wing bomber in these areas in around thirty minutes after re-locating to a SRZ airbase. Airbases in Primary Response Zones should be a minimum Category B, but a Category C Airbase with an Air Ops Brigade close at hand may be acceptable.Airbases in the Secondary Response Zone should be a minimum of Category C. This may be varied when special operational or risk circumstances prevail or a Contractor installs their own company facilities.Operational Requirements may dictate the need to operate out of a temporary airbase which is not currently recognised by State Aviation Operations. The decision to then operate out of temporary airbase resides with aircraft pilots and SACFS aircrew to ensure all safety and Operational Requirements are met.In addition to meeting the performance requirements of the aircraft, the safety and welfare needs of the Ground Filling Crews must also be met. This will be carried out by conducting risk assessments and considering incident and operational imperatives.SACFS aircrew may liaise with other key personnel such as Incident Controllers, Land Management Agencies and Land Owners during the decision making process. Spatial Reference: South Australia Lambert (GDA 2020); EPSG: 8059

Service Item Id: bfa8e00e963f4ca8b9ef510703ee703c

Copyright Text: South Australian Country Fire Service

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1041703.1006999984
YMin: 1349138.9910000004
XMax: 1516108.1014000028
YMax: 1937851.6837000009
Spatial Reference: 8059  (8059)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: status
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Primary
  Label: Primary
  Description: N/A
  Symbol:

• Value: Secondary
  Label: Secondary
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• objectid ( type: esriFieldTypeOID, alias: OBJECTID )
• airbase ( type: esriFieldTypeString, alias: Airbase, length: 8000 )
• category ( type: esriFieldTypeString, alias: Category, length: 8000 )
• address ( type: esriFieldTypeString, alias: Address, length: 8000 )
• status ( type: esriFieldTypeString, alias: Status, length: 8000 )
• shape ( type: esriFieldTypeGeometry, alias: Shape )
• code ( type: esriFieldTypeString, alias: code, length: 8000 )
• water_prim ( type: esriFieldTypeString, alias: water_prim, length: 8000 )
• water_sec ( type: esriFieldTypeString, alias: water_sec, length: 8000 )
• water_supply ( type: esriFieldTypeString, alias: water_supply, length: 8000 )
• pump ( type: esriFieldTypeString, alias: pump, length: 8000 )
• generator ( type: esriFieldTypeString, alias: generator, length: 8000 )
• foam ( type: esriFieldTypeString, alias: foam, length: 8000 )
• retardant ( type: esriFieldTypeString, alias: retardant, length: 8000 )
• gel ( type: esriFieldTypeString, alias: gel, length: 8000 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
